Kiloview - N1
Brand:
Wireless NDI Encoder
Risoluzione max:1080p60
Ritardo non superiore a 67ms
Protocolli supportati: NDI|HX, RTMP, HLS,TS over UDP, SIP
Video Encoding/Audio Encoding: H.264, NDI|HX/ AAC or G.711
Batteria integrata 6800mAh con durata massima superiore alle 3 ore.
Supporta voltaggi in ingresso 5-16V per essere compatibile con altre batterie esterne o power bank esterni.
Supporto di montaggio: Hot Shoe
Rete: Ethernet by USB, WiFi
Setup tramite controllo remoto via app
Slot per scheda MicroSD per registrazione locale
Può anche registrare tramite rete su storage NAS.
| Input | N1:1*SDI N2:1*HDMI |
| Transmission mode | Enhanced WIFI, Ethernet by USB expansion |
| Media protocol | NDI-HX/RTSP/RTMP/SRT/HLS/TS over UDP |
| Video resolution | Up to 1080P60Hz: 1080p23.98/24/25/29.97/30 1080p50/59.94/60 1080i50/59.94/60 720p23.98/24/25/29.97/30 720p50/59.94/60 |
| Video encoding | H264/AVC, Motion-JPEG |
| Audio encoding | AAC/G.711 |
| Latency | Using NDI protocol for end-to-end latency by Ethernet is about 150ms |
| Graphic overlay | Support custom text, image overlay function, and superimposed to any position on the screen |
| Management | APP/Web |
| Audio Intercom | Supported (KV Apps Required) |
| Recording | Micro SD/TF card slot, local recording, NAS network storage |
| Hot shoe | Removable |
| Battery | Detachable |
| Battery capacity | 3.7V 6800mAh (29.6Wh) |
| Power supply | DC 12V 1A |
| Power Consumption | 6.5w |
